IHTH-1500MZ-5A .47 20% EB E2
IHTH1500MZEBR47M5A is a Fixed Inductors manufactured by Vishay Dale. IHTH-1500MZ-5A .47 20% EB E2. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 155°C, package / case Radial, Vertical Cylinder, 4 Leads, current rating (amps) 134.8 A.
In Stock: 29
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | - |
| Material - Core | Metal Composite |
| Inductance | 470 nH |
| Tolerance | ±20% |
| Current Rating (Amps) | 134.8 A |
| Current - Saturation (Isat) | 156.2A |
| Shielding | Shielded |
| DC Resistance (DCR) | 0.2mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | 54.1MHz |
| Ratings | - |
| Operating Temperature | -55°C ~ 155°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Vertical Cylinder, 4 Leads |
| Supplier Device Package | Radial |
| Size / Dimension | 1.500" Dia (38.10mm) |
| Height - Seated (Max) | 0.502" (12.76mm) |
Submit your RFQ for IHTH1500MZEBR47M5A and get a quote within 24 hours.
