MAGNETICALLY SHIELDED DOME DRIVE
SC 5 - 8 OHM is a Speakers manufactured by Visaton GmbH & Co. KG. MAGNETICALLY SHIELDED DOME DRIVE. Key specifications: size / dimension 5.236" Dia x 2.028" L (133.00mm x 51.50mm), termination Quick Connect, power - max 100 W, frequency range 1.5 kHz ~ 22 kHz.
In Stock: 34
| Attribute | Value |
|---|---|
| Product Status | Active |
| Technology | Magnetic |
| Type | General Purpose |
| Frequency Range | 1.5 kHz ~ 22 kHz |
| Frequency - Self Resonant | 2kHz |
| Impedance | 8 Ohms |
| Efficiency - dBA | 90.00 |
| Efficiency - Testing | 1W/1M |
| Efficiency - Type | Sound Pressure Level (SPL) |
| Power - Rated | 60 W |
| Power - Max | 100 W |
| Port Location | Top |
| Shape | Round, Square Frame |
| Material - Cone | - |
| Material - Magnet | - |
| Ingress Protection | - |
| Ratings | - |
| Termination | Quick Connect |
| Size / Dimension | 5.236" Dia x 2.028" L (133.00mm x 51.50mm) |
| Height - Seated (Max) | 0.992" (25.20mm) |
Submit your RFQ for SC 5 - 8 OHM and get a quote within 24 hours.
