PLCC LED 2020 FLAT LENS RGB
PLCC2020FRGB1T is a LED Indication - Discrete manufactured by Venkel. PLCC LED 2020 FLAT LENS RGB. Key specifications: mounting type Surface Mount, voltage - forward (vf) (typ) 2.1V Red, 3.1V Green, 3.1V Blue, package / case 6-PLCC, color Red, Green, Blue (RGB).
In Stock: 17,000
| Attribute | Value |
|---|---|
| Product Status | Active |
| Color | Red, Green, Blue (RGB) |
| Configuration | Independent |
| Lens Color | Colorless |
| Lens Transparency | Clear |
| Millicandela Rating | 800mcd Red, 1700mcd Green, 300mcd Blue |
| Lens Style | Square with Flat Top |
| Lens Size | 5.00mm x 5.00mm |
| Voltage - Forward (Vf) (Typ) | 2.1V Red, 3.1V Green, 3.1V Blue |
| Current - Test | 30mA |
| Viewing Angle | 120° |
| Mounting Type | Surface Mount |
| Wavelength - Dominant | 624nm Red, 525nm Green, 467nm Blue |
| Wavelength - Peak | 628nm Red, 523nm Green, 472nm Blue |
| Features | - |
| Package / Case | 6-PLCC |
| Supplier Device Package | 6-PLCC |
| Size / Dimension | 5.00mm L x 5.00mm W |
| Height (Max) | 1.70mm |
Submit your RFQ for PLCC2020FRGB1T and get a quote within 24 hours.
