CAP ALUM 1500UF 20% 25V RADIAL
ELZA250ELL152MK20S is a Aluminum Electrolytic Capacitors manufactured by United Chemi-Con. CAP ALUM 1500UF 20% 25V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 25 V, package / case Radial, Can.
In Stock: 3,352
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 1500 µF |
| Tolerance | ±20% |
| Voltage - Rated | 25 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Ripple Current @ Low Frequency | 1.134 A @ 120 Hz |
| Ripple Current @ High Frequency | 1.89 A @ 100 kHz |
| Impedance | 29 mOhms |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.492" Dia (12.50mm) |
| Height - Seated (Max) | 0.846" (21.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| ELXZ250EC3152MK25S | United Chemi-Con | CAP ALUM 1500UF 20% 25V RADIAL | 98% | View |
| 860080478022 | Würth Elektronik | CAP ALUM 1500UF 20% 25V RADIAL | 87% | View |
| MAL213655152E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 1500UF 20% 16V RADIAL | 81% | View |
| EY1C152MNN1220 | Chinsan (Elite) | ALUMINUM ELECTROLYTIC CAPACITORS | 78% | View |
| MAL211946152E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 1500UF 25V AXIAL | 76% | View |
| EEU-FC1A152B | Panasonic Electronic Components | CAP ALUM 1500UF 20% 10V RADIAL | 70% | View |
