CAP ALUM 1000UF 20% 16V RADIAL
ELZA160ELL102MJ16S is a Aluminum Electrolytic Capacitors manufactured by United Chemi-Con. CAP ALUM 1000UF 20% 16V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 16 V, package / case Radial, Can.
In Stock: 1,938
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 1000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 16 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 4000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Ripple Current @ Low Frequency | 744 mA @ 120 Hz |
| Ripple Current @ High Frequency | 1.24 A @ 100 kHz |
| Impedance | 49 mOhms |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.689" (17.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UVZ1E102MPD1CA | Nichicon | CAP ALUM 25V POLAR | 73% | View |
| UVZ1E102MPD1AL | Nichicon | CAP ALUM 25V POLAR | 73% | View |
| MAL226050102E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 1000UF 20% 35V RADIAL | 71% | View |
| 35YXA1000MEFCG412.5X20 | Rubycon | CAP ALUM 1000UF 20% 35V RADIAL | 71% | View |
| ECA-1JHG102E | Panasonic Electronic Components | CAP ALUM 1000UF 20% 63V RADIAL | 70% | View |
| 517D108M010CD6AE3 | Vishay Sprague | CAP ALUM 1000UF 20% 10V RADIAL | 64% | View |
Submit your RFQ for ELZA160ELL102MJ16S and get a quote within 24 hours.
