CAP ALUM 390UF 20% 6.3V RADIAL
ELXV6R3ELL391MH12D is a Aluminum Electrolytic Capacitors manufactured by United Chemi-Con. CAP ALUM 390UF 20% 6.3V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 6.3 V, package / case Radial, Can.
In Stock: 8,038
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 390 µF |
| Tolerance | ±20% |
| Voltage - Rated | 6.3 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Ripple Current @ Low Frequency | 269.75 mA @ 120 Hz |
| Ripple Current @ High Frequency | 415 mA @ 100 kHz |
| Impedance | 200 mOhms |
| Lead Spacing | 0.138" (3.50mm) |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.531" (13.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EEU-FC1A391B | Panasonic Electronic Components | CAP ALUM 390UF 20% 10V RADIAL | 66% | View |
| MAL213654391E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 390UF 20% 10V RADIAL | 63% | View |
| ELXV100ELL391MJC5S | United Chemi-Con | CAP ALUM 390UF 20% 10V RADIAL | 62% | View |
| 672D397H040ET5C | Vishay Sprague | CAP ALUM 390UF 40V RADIAL | 56% | View |
| 672D397H020DM5J | Vishay Sprague | CAP ALUM 390UF 20V RADIAL | 56% | View |
| 672D397H040DS5R | Vishay Sprague | CAP ALUM 390UF 40V RADIAL | 56% | View |
Submit your RFQ for ELXV6R3ELL391MH12D and get a quote within 24 hours.
