CAP ALUM 120UF 20% 35V RADIAL
ELXV350ELL121MH12D is a Aluminum Electrolytic Capacitors manufactured by United Chemi-Con. CAP ALUM 120UF 20% 35V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 35 V, package / case Radial, Can.
In Stock: 2,055
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 120 µF |
| Tolerance | ±20% |
| Voltage - Rated | 35 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Ripple Current @ Low Frequency | 166 mA @ 120 Hz |
| Ripple Current @ High Frequency | 415 mA @ 100 kHz |
| Impedance | 200 mOhms |
| Lead Spacing | 0.138" (3.50mm) |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.531" (13.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| B41858D7127M8 | EPCOS - TDK Electronics | CAP ALUM 120UF 20% 35V RADIAL | 95% | View |
| 678D127M025CC4D | Vishay Sprague | CAP ALUM 120UF 20% 25V RADIAL | 78% | View |
| EEU-FC1E121H | Panasonic Electronic Components | CAP ALUM 120UF 20% 25V RADIAL | 78% | View |
| MAL213668121E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 120UF 20% 63V RADIAL | 68% | View |
| ELXV630EMC121MJ20S | United Chemi-Con | CAP ALUM 120UF 20% 63V RADIAL | 66% | View |
| 672D127H050DT2C | Vishay Sprague | CAP ALUM 120UF 60V RADIAL | 65% | View |
Submit your RFQ for ELXV350ELL121MH12D and get a quote within 24 hours.
