CAP ALUM 22UF 20% 100V RADIAL
ELXV101ELL220MH12D is a Aluminum Electrolytic Capacitors manufactured by United Chemi-Con. CAP ALUM 22UF 20% 100V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 100 V, package / case Radial, Can.
In Stock: 6,781
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 22 µF |
| Tolerance | ±20% |
| Voltage - Rated | 100 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Ripple Current @ Low Frequency | 55 mA @ 120 Hz |
| Ripple Current @ High Frequency | 275 mA @ 100 kHz |
| Impedance | 530 mOhms |
| Lead Spacing | 0.138" (3.50mm) |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.531" (13.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 517D226M100BB6AE3 | Vishay Sprague | CAP ALUM 22UF 20% 100V RADIAL | 78% | View |
| UBW2A220MPD | Nichicon | CAP ALUM 22UF 20% 100V RADIAL | 61% | View |
| ELXZ500ELL220MEB5D | United Chemi-Con | CAP ALUM 22UF 20% 50V RADIAL | 61% | View |
| MAL211658229E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 22UF 20% 63V RADIAL | 55% | View |
| UBW1J220MPD1TA | Nichicon | CAP ALUM 22UF 20% 63V RADIAL | 55% | View |
| EKRG500ETD220MF07D | United Chemi-Con | CAP ALUM 22UF 20% 50V RADIAL | 54% | View |
Submit your RFQ for ELXV101ELL220MH12D and get a quote within 24 hours.
