CAP ALUM 22UF 20% 100V RADIAL
ELXV101EC3220MH12D is a Aluminum Electrolytic Capacitors manufactured by United Chemi-Con. CAP ALUM 22UF 20% 100V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 100 V, package / case Radial, Can.
In Stock: 6,226
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 22 µF |
| Tolerance | ±20% |
| Voltage - Rated | 100 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Ripple Current @ Low Frequency | 55 mA @ 120 Hz |
| Ripple Current @ High Frequency | 275 mA @ 100 kHz |
| Impedance | 530 mOhms |
| Lead Spacing | 0.138" (3.50mm) |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.531" (13.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UPW2A220MPD1CV | Nichicon | CAP ALUM 100V POLAR | 90% | View |
| UPM1J220MED1TD | Nichicon | CAP ALUM 22UF 20% 63V RADIAL | 68% | View |
| LXZ63VB22RM6X11LL | United Chemi-Con | CAP ALUM 22UF 20% 63V RADIAL | 66% | View |
| UVZ0J220MDD1TA | Nichicon | CAP ALUM 22UF 20% 6.3V RADIAL | 65% | View |
| UST1C220MDD1TE | Nichicon | CAP ALUM 22UF 20% 16V RADIAL | 64% | View |
| EKMG160ELL220ME11D | United Chemi-Con | CAP ALUM 22UF 20% 16V RADIAL | 51% | View |
Submit your RFQ for ELXV101EC3220MH12D and get a quote within 24 hours.
