CAP ALUM 560UF 20% 80V RADIAL
EKZE800ELL561MK40S is a Aluminum Electrolytic Capacitors manufactured by United Chemi-Con. CAP ALUM 560UF 20% 80V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 80 V, package / case Radial, Can.
In Stock: 1,711
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 560 µF |
| Tolerance | ±20% |
| Voltage - Rated | 80 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 900 mA @ 120 Hz |
| Ripple Current @ High Frequency | 1.8 A @ 100 kHz |
| Impedance | 32 mOhms |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.492" Dia (12.50mm) |
| Height - Seated (Max) | 1.634" (41.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MAL214658561E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 560UF 20% 63V RADIAL | 85% | View |
| 50YXS560MEFC16X16 | Rubycon | CAP ALUM 560UF 20% 50V RADIAL | 79% | View |
| 63YXG560MEFC16X25 | Rubycon | CAP ALUM 560UF 20% 63V RADIAL | 70% | View |
| ELXV250ELL561MJ25S | United Chemi-Con | CAP ALUM 560UF 20% 25V RADIAL | 66% | View |
| 16ZLK560MT810X12.5 | Rubycon | CAP ALUM 560UF 20% 16V RADIAL | 65% | View |
| MAL215819561E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 560UF 20% 100V SNAP | 64% | View |
Submit your RFQ for EKZE800ELL561MK40S and get a quote within 24 hours.
