CAP ALUM 560UF 20% 100V RADIAL
EKYB101ELL561MLP1S is a Aluminum Electrolytic Capacitors manufactured by United Chemi-Con. CAP ALUM 560UF 20% 100V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 100 V, package / case Radial, Can.
In Stock: 3,151
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 560 µF |
| Tolerance | ±20% |
| Voltage - Rated | 100 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 10000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.3 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.6 A @ 100 kHz |
| Impedance | 20 mOhms |
| Lead Spacing | 0.295" (7.50mm) |
| Size / Dimension | 0.630" Dia (16.00mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 601D567F100JP3 | Vishay Sprague | CAP ALUM 560UF 100V AXIAL | 100% | View |
| 100ZL560MEFC16X40 | Rubycon | CAP ALUM 560UF 20% 100V RADIAL | 92% | View |
| 100ZLJ560M16X35.5 | Rubycon | CAP ALUM 560UF 20% 100V RADIAL | 89% | View |
| 100ZL560MEFCGC18X35.5 | Rubycon | CAP ALUM 560UF 20% 100V RADIAL | 87% | View |
| 35ZLG560MEFCT810X23 | Rubycon | CAP ALUM 560UF 20% 35V RADIAL | 74% | View |
| EEU-FR1V561 | Panasonic Electronic Components | CAP ALUM 560UF 20% 35V RADIAL | 73% | View |
