CAP ALUM 390UF 20% 450V SNAP
EKMH451VQT391MB35T is a Aluminum Electrolytic Capacitors manufactured by United Chemi-Con. CAP ALUM 390UF 20% 450V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 450 V, package / case Radial, Can - Snap-In - 5 Lead.
In Stock: 8,425
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 390 µF |
| Tolerance | ±20% |
| Voltage - Rated | 450 V |
| ESR (Equivalent Series Resistance) | 638mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.57 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.2451 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.984" (25.00mm) |
| Size / Dimension | 1.575" Dia (40.00mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In - 5 Lead |
EKMH451VQT391MB35T is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| B43508B5397M000 | EPCOS - TDK Electronics | CAP ALUM 390UF 20% 450V SNAP | 99% | View |
| EKMH351VNN391MR45S | United Chemi-Con | CAP ALUM 390UF 20% 350V SNAP | 91% | View |
| 500MXH390MEFCSN30X60 | Rubycon | CAP ALUM 390UF 20% 500V SNAP | 84% | View |
| LKX2D391MESZ30 | Nichicon | CAP ALUM 390UF 20% 200V SNAP | 71% | View |
| B43508F2397M87 | EPCOS - TDK Electronics | CAP ALUM 390UF 20% 250V SNAP | 70% | View |
| EEU-FC2A391L | Panasonic Electronic Components | CAP ALUM 390UF 20% 100V RADIAL | 68% | View |
Submit your RFQ for EKMH451VQT391MB35T and get a quote within 24 hours.
