CAP ALUM 2.2UF 20% 50V SMD
BMVK500ADA2R2ME60G is a Aluminum Electrolytic Capacitors manufactured by United Chemi-Con. CAP ALUM 2.2UF 20% 50V SMD. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 105°C, voltage - rated 50 V, package / case Radial, Can - SMD.
In Stock: 8,277
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 2.2 µF |
| Tolerance | ±20% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 1000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Bi-Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 10 mA @ 120 Hz |
| Ripple Current @ High Frequency | - |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.197" Dia (5.00mm) |
| Height - Seated (Max) | 0.224" (5.70mm) |
| Surface Mount Land Size | 0.209" L x 0.209" W (5.30mm x 5.30mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MVY50VC2R2MD55TP | United Chemi-Con | CAP ALUM 2.2UF 20% 50V SMD | 100% | View |
| EMVY500ADA2R2MD55G | United Chemi-Con | CAP ALUM 2.2UF 20% 50V SMD | 98% | View |
| EEE-HD1H2R2R | Panasonic Electronic Components | CAP ALUM 2.2UF 20% 50V SMD | 94% | View |
| EMVE500ADA2R2MD55G | United Chemi-Con | CAP ALUM 2.2UF 20% 50V SMD | 94% | View |
| 225AXZ050M | Cornell Dubilier / Illinois Capacitor | CAP ALUM 2.2UF 20% 50V SMD | 87% | View |
| EEE-HB1H2R2AR | Panasonic Electronic Components | CAP ALUM 2.2UF 20% 50V SMD | 85% | View |
Submit your RFQ for BMVK500ADA2R2ME60G and get a quote within 24 hours.
