DC/DC CONVERTER 56V 35W
TP-DCDC-1248GD-HP is a DC DC Converters manufactured by Tycon Systems Inc.. DC/DC CONVERTER 56V 35W. Key specifications: mounting type Chassis Mount, operating temperature -30°C ~ 60°C, current - output (max) 625mA, size / dimension 4.92" L x 2.95" W x 1.50" H (125.0mm x 75.0mm x 38.0mm).
In Stock: 249
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Enclosed |
| Voltage - Input (Min) | 10V |
| Voltage - Input (Max) | 15V |
| Number of Outputs | 1 |
| Voltage - Output 1 | 56V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 625mA |
| Power (Watts) | 35W |
| Voltage - Isolation | - |
| Applications | ITE (Commercial) |
| Efficiency | 75% |
| Operating Temperature | -30°C ~ 60°C |
| Mounting Type | Chassis Mount |
| Size / Dimension | 4.92" L x 2.95" W x 1.50" H (125.0mm x 75.0mm x 38.0mm) |
| Approval Agency | - |
| Standard Number | - |
Submit your RFQ for TP-DCDC-1248GD-HP and get a quote within 24 hours.
