FIXED IND 27UH 1.44A 100 MOHM
HM79-50270LFTR13 is a Fixed Inductors manufactured by TT Electronics/BI Magnetics. FIXED IND 27UH 1.44A 100 MOHM. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C, package / case Nonstandard, current rating (amps) 1.44 A.
In Stock: 881
| Attribute | Value |
|---|---|
| Product Status | Discontinued at Digi-Key |
| Type | Wirewound |
| Material - Core | - |
| Inductance | 27 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 1.44 A |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 100mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 1 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.394" L x 0.354" W (10.00mm x 9.00mm) |
| Height - Seated (Max) | 0.157" (4.00mm) |
Submit your RFQ for HM79-50270LFTR13 and get a quote within 24 hours.
