TRANSF 600 AUDIO CT 150/600CT 15
TY-146P is a Audio Transformers manufactured by Triad Magnetics. TRANSF 600 AUDIO CT 150/600CT 15. Key specifications: mounting type Through Hole, operating temperature -20°C ~ 85°C, size / dimension 1.375" L x 1.187" W (34.93mm x 30.15mm), termination style PC Pin.
In Stock: 6,464
| Attribute | Value |
|---|---|
| Product Status | Active |
| Turns Ratio - Primary:Secondary | 1:1 |
| Impedance - Primary (Ohms) | 600, 150/150 |
| Impedance - Secondary (Ohms) | 600, 150/150 |
| DC Resistance (DCR) - Primary | 17Ohm, 19Ohm |
| DC Resistance (DCR) - Secondary | 14.5Ohm, 22Ohm |
| Transformer Type | Data/Voice Coupling |
| Frequency Range | 200Hz ~ 15kHz |
| Frequency Response | ±2dB |
| Voltage - Isolation | 1500V |
| Insertion Loss | 1.5dB |
| Return Loss | 26dB |
| Power Level | 1W |
| Operating Temperature | -20°C ~ 85°C |
| Approval Agency | - |
| Mounting Type | Through Hole |
| Size / Dimension | 1.375" L x 1.187" W (34.93mm x 30.15mm) |
| Height - Seated (Max) | 1.187" (30.15mm) |
| Termination Style | PC Pin |
Submit your RFQ for TY-146P and get a quote within 24 hours.
