Toshiba Semiconductor and Storage
IC MOTOR DRIVER 10V-36V 24SDIP
TB6561NG,8 is a PMIC - Motor Drivers, Controllers manufactured by Toshiba Semiconductor and Storage. IC MOTOR DRIVER 10V-36V 24SDIP. Key specifications: mounting type Through Hole, operating temperature -20°C ~ 85°C (TA), voltage - supply 10V ~ 36V, package / case 24-SDIP (0.300", 7.62mm).
In Stock: 3,943
| Attribute | Value |
|---|---|
| Product Status | Active |
| Motor Type - Stepper | - |
| Motor Type - AC, DC | Brushed DC |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Output Configuration | Half Bridge (4) |
| Interface | PWM |
| Technology | Bi-CMOS |
| Step Resolution | - |
| Applications | General Purpose |
| Current - Output | 1.5A |
| Voltage - Supply | 10V ~ 36V |
| Voltage - Load | 10V ~ 36V |
| Operating Temperature | -20°C ~ 85°C (TA) |
| Mounting Type | Through Hole |
| Package / Case | 24-SDIP (0.300", 7.62mm) |
| Supplier Device Package | 24-SDIP |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| SLA7032M | Sanken | IC MTR DRV UNIPOLAR 10-44V 18ZIP | 100% | View |
| L6229N | STMicroelectronics | IC MOTOR DRVR 12V-52V 24POWERDIP | 91% | View |
| L6225N | STMicroelectronics | IC MTR DRV BIPLR 8-52V 20-PWRDIP | 89% | View |
| L6228N | STMicroelectronics | IC MTR DRVR BIPLR 8-52V 24PWRDIP | 89% | View |
| SMA6822MHLF2451 | Sanken | IC MOTOR DRVR 13.5V-16.5V 24SIP | 66% | View |
| SMA6822MH | Sanken | IC MOTOR DRVR 13.5V-16.5V 24ZIP | 66% | View |
Submit your RFQ for TB6561NG,8 and get a quote within 24 hours.
