LED DRIVER CC AC/DC 13-22V 900MA
BLED20W-022-C0900 is a LED Drivers manufactured by Thomas Research Products. LED DRIVER CC AC/DC 13-22V 900MA. Key specifications: voltage - output 13 ~ 22V, current - output (max) 900mA, size / dimension 2.72" L x 2.04" W x 1.03" H (69.0mm x 51.8mm x 26.0mm), termination style Wire Leads.
In Stock: 406
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Type | Constant Current |
| Topology | AC DC Converter |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 90VAC |
| Voltage - Input (Max) | 305VAC |
| Voltage - Output | 13 ~ 22V |
| Current - Output (Max) | 900mA |
| Power (Watts) | 20 W |
| Voltage - Isolation | - |
| Dimming | - |
| Features | OCP, OVP, SCP |
| Ratings | IP64 |
| Operating Temperature | - |
| Efficiency | 83% |
| Termination Style | Wire Leads |
| Size / Dimension | 2.72" L x 2.04" W x 1.03" H (69.0mm x 51.8mm x 26.0mm) |
| Approval Agency | cURus |
| Standard Number | - |
Submit your RFQ for BLED20W-022-C0900 and get a quote within 24 hours.
