LED DRIVER CC AC/DC 11-18V 1.11A
BLED20W-018-C1110 is a LED Drivers manufactured by Thomas Research Products. LED DRIVER CC AC/DC 11-18V 1.11A. Key specifications: voltage - output 11 ~ 18V, current - output (max) 1.11A, size / dimension 2.72" L x 2.04" W x 1.03" H (69.0mm x 51.8mm x 26.0mm), termination style Wire Leads.
In Stock: 99
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Type | Constant Current |
| Topology | AC DC Converter |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 90VAC |
| Voltage - Input (Max) | 305VAC |
| Voltage - Output | 11 ~ 18V |
| Current - Output (Max) | 1.11A |
| Power (Watts) | 20 W |
| Voltage - Isolation | - |
| Dimming | - |
| Features | OCP, OVP, SCP |
| Ratings | IP64 |
| Operating Temperature | - |
| Efficiency | 83% |
| Termination Style | Wire Leads |
| Size / Dimension | 2.72" L x 2.04" W x 1.03" H (69.0mm x 51.8mm x 26.0mm) |
| Approval Agency | cURus |
| Standard Number | - |
