IC GATE NAND 4CH 2-INP 14TSSOP
SN74HC00APW is a Logic - Gates and Inverters manufactured by Texas Instruments. IC GATE NAND 4CH 2-INP 14TSSOP. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C, voltage - supply 2V ~ 6V, package / case 14-TSSOP (0.173", 4.40mm Width).
In Stock: 8,710
| Attribute | Value |
|---|---|
| Product Status | Active |
| Logic Type | NAND Gate |
| Number of Circuits | 4 |
| Number of Inputs | 2 |
| Features | - |
| Voltage - Supply | 2V ~ 6V |
| Current - Quiescent (Max) | 2 µA |
| Current - Output High, Low | 5.2mA, 5.2mA |
| Logic Level - Low | 0.1V ~ 0.26V |
| Logic Level - High | 1.9V ~ 5.9V |
| Max Propagation Delay @ V, Max CL | 13ns @ 6V, 50pF |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 14-TSSOP |
| Package / Case | 14-TSSOP (0.173", 4.40mm Width) |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 74HC132PW/C4118 | NXP USA Inc. | IC GATE NAND 4CH 2-INP 14TSSOP | 84% | View |
| MC74HC132ADTG | onsemi | IC GATE NAND 4CH 2-INP 14TSSOP | 80% | View |
| 74HC20PW/C118 | NXP USA Inc. | IC GATE NAND 2CH 4-INP 14TSSOP | 78% | View |
| MC74HC20ADG | onsemi | IC GATE NAND 2CH 4-INP 14SOIC | 73% | View |
| MC74HC20FEL | Motorola | IC GATE NAND 2CH 4-INP SOEIAJ-14 | 73% | View |
| 74HC00D/AUJ | NXP USA Inc. | IC GATE NAND 4CH 2-INP 14SO | 69% | View |
Submit your RFQ for SN74HC00APW and get a quote within 24 hours.
