DC DC CONVERTER 1.3-2.05V
PT7712N is a DC DC Converters manufactured by Texas Instruments. DC DC CONVERTER 1.3-2.05V. Key specifications: mounting type Through Hole, Vertical, operating temperature -40°C ~ 85°C, package / case 27-SIP Module, Vertical, current - output (max) 20A.
In Stock: 90
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Type | Non-Isolated PoL Module |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 3.1V |
| Voltage - Input (Max) | 3.6V |
| Voltage - Output 1 | 1.3 ~ 2.05V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 20A |
| Power (Watts) | - |
| Voltage - Isolation | - |
| Applications | ITE (Commercial) |
| Features | - |
| Operating Temperature | -40°C ~ 85°C |
| Efficiency | 83% |
| Mounting Type | Through Hole, Vertical |
| Package / Case | 27-SIP Module, Vertical |
| Size / Dimension | 3.00" L x 0.66" W x 1.02" H (76.2mm x 16.8mm x 25.9mm) |
| Supplier Device Package | - |
| Control Features | - |
| Approval Agency | - |
| Standard Number | - |
