IC GATE DRVR HALF-BRIDGE 8SOIC
LM5109BMAX is a PMIC - Gate Drivers manufactured by Texas Instruments. IC GATE DRVR HALF-BRIDGE 8SOIC. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 125°C (TJ), voltage - supply 8V ~ 14V, package / case 8-SOIC (0.154", 3.90mm Width).
In Stock: 8,093
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Driven Configuration | Half-Bridge |
| Channel Type | Independent |
| Number of Drivers | 2 |
| Gate Type | N-Channel MOSFET |
| Voltage - Supply | 8V ~ 14V |
| Logic Voltage - VIL, VIH | 0.8V, 2.2V |
| Current - Peak Output (Source, Sink) | 1A, 1A |
| Input Type | Non-Inverting |
| High Side Voltage - Max (Bootstrap) | 108 V |
| Rise / Fall Time (Typ) | 15ns, 15ns |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
LM5109BMAX is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| LM5109AMA | Texas Instruments | IC GATE DRVR HALF-BRIDGE 8SOIC | 100% | View |
| FAN3278TMX | onsemi | IC GATE DRVR HALF-BRIDGE 8SOIC | 96% | View |
| MIC4605-1YM-T5 | Microchip Technology | IC GATE DRVR HALF-BRIDGE 8SOIC | 93% | View |
| IRS2011STRPBF | Infineon Technologies | IC GATE DRVR HALF-BRIDGE 8SOIC | 85% | View |
| HIP2103FRTAAZ | Renesas Electronics America Inc | IC GATE DRVR HALF-BRIDGE 8TDFN | 74% | View |
| HIP2104FRAANZ-T | Renesas Electronics America Inc | IC GATE DRVR HALF-BRIDGE 12DFN | 74% | View |
Submit your RFQ for LM5109BMAX and get a quote within 24 hours.
