IC INST AMP 1 CIRCUIT 8CFP
INA333SHKQ is a Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps manufactured by Texas Instruments. IC INST AMP 1 CIRCUIT 8CFP. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 210°C, package / case 8-CSOIC (0.220", 5.65mm Width), current - supply 50µA.
In Stock: 4,792
| Attribute | Value |
|---|---|
| Product Status | Active |
| Amplifier Type | Instrumentation |
| Number of Circuits | 1 |
| Output Type | Rail-to-Rail |
| Slew Rate | 0.16V/µs |
| Gain Bandwidth Product | - |
| -3db Bandwidth | 150 kHz |
| Current - Input Bias | 70 pA |
| Voltage - Input Offset | 10 µV |
| Current - Supply | 50µA |
| Current - Output / Channel | 55 mA |
| Voltage - Supply Span (Min) | 1.8 V |
| Voltage - Supply Span (Max) | 5.5 V |
| Operating Temperature | -55°C ~ 210°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-CSOIC (0.220", 5.65mm Width) |
| Supplier Device Package | 8-CFP |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| INA333SHKJ | Texas Instruments | IC INST AMP 1 CIRCUIT 8CFP | 100% | View |
| OPA2333SHKJ | Texas Instruments | IC OPAMP ZERO-DRIFT 2 CIRC 8CFP | 66% | View |
| OPA2333SHKQ | Texas Instruments | IC OPAMP ZERO-DRIFT 2 CIRC 8CFP | 66% | View |
| OPA2333SKGD1 | Texas Instruments | IC OPAMP ZERO-DRIFT 2 CIRC DIE | 66% | View |
