TE Connectivity Potter & Brumfield Relays
RELAY GEN PURP DPDT 200MA 24VDC
8-1393806-7 is a Signal Relays, Up to 2 Amps manufactured by TE Connectivity Potter & Brumfield Relays. RELAY GEN PURP DPDT 200MA 24VDC. Key specifications: mounting type Socketable, operating temperature -40°C ~ 70°C, contact material Gold (Au), termination style Plug In.
In Stock: 1
| Attribute | Value |
|---|---|
| Product Status | Discontinued at Digi-Key |
| Mounting Type | Socketable |
| Coil Voltage | 24VDC |
| Contact Form | DPDT (2 Form C) |
| Contact Rating (Current) | 200 mA |
| Switching Voltage | 30VAC, 36VDC - Max |
| Coil Current | 27 mA |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | Plug In |
| Seal Rating | - |
| Coil Insulation | - |
| Must Operate Voltage | 11 VDC |
| Must Release Voltage | - |
| Operate Time | 7.5 ms |
| Release Time | 3 ms |
| Operating Temperature | -40°C ~ 70°C |
| Contact Material | Gold (Au) |
| Relay Type | General Purpose |
