TE Connectivity AMP Connectors
CONN RCPT 8POS 0.049 TIN SMD
3-1827159-8 is a Rectangular Connectors - Headers, Receptacles, Female Sockets manufactured by TE Connectivity AMP Connectors. CONN RCPT 8POS 0.049 TIN SMD. Key specifications: mounting type Surface Mount, operating temperature -30°C ~ 105°C, voltage rating 50V, current rating (amps) 0.5A.
In Stock: 3,999
| Attribute | Value |
|---|---|
| Product Status | Active |
| Connector Type | Receptacle |
| Contact Type | Forked |
| Style | Board to Board |
| Number of Positions | 8 |
| Number of Positions Loaded | All |
| Pitch - Mating | 0.049" (1.25mm) |
| Number of Rows | 1 |
| Row Spacing - Mating | - |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Fastening Type | Push-Pull |
| Contact Finish - Mating | Tin |
| Contact Finish Thickness - Mating | - |
| Insulation Color | - |
| Insulation Height | 0.134" (3.40mm) |
| Contact Length - Post | - |
| Operating Temperature | -30°C ~ 105°C |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish - Post | Tin |
| Mated Stacking Heights | - |
| Ingress Protection | - |
| Features | Board Guide, Pick and Place |
| Current Rating (Amps) | 0.5A |
| Voltage Rating | 50V |
Submit your RFQ for 3-1827159-8 and get a quote within 24 hours.
