TE Connectivity Aerospace, Defense and Marine
CONN EDGE DUAL FMALE 86POS 0.156
3-530677-3 is a Card Edge Connectors - Edgeboard Connectors manufactured by TE Connectivity Aerospace, Defense and Marine. CONN EDGE DUAL FMALE 86POS 0.156. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, color Black, contact material Phosphor Bronze.
In Stock: 17
| Attribute | Value |
|---|---|
| Product Status | Active |
| Card Type | Non Specified - Dual Edge |
| Gender | Female |
| Number of Positions/Bay/Row | - |
| Number of Positions | 86 |
| Card Thickness | 0.055" ~ 0.070" (1.40mm ~ 1.78mm) |
| Number of Rows | 2 |
| Pitch | 0.156" (3.96mm) |
| Read Out | Dual |
| Features | - |
| Mounting Type | Through Hole |
| Termination | Solder |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Contact Type | Hairpin Bellows |
| Color | Black |
| Flange Feature | Flush Mount, Top Opening, Threaded Insert, 4-40 |
| Operating Temperature | -55°C ~ 105°C |
Submit your RFQ for 3-530677-3 and get a quote within 24 hours.
