AC/DC CONVERTER 5V +/-15V 50W
LWT50H-5FF is a AC DC Converters manufactured by TDK-Lambda Americas Inc. AC/DC CONVERTER 5V +/-15V 50W. Key specifications: mounting type Chassis Mount, operating temperature 0°C ~ 60°C (With Derating), voltage - input 85 ~ 265 VAC, size / dimension 6.29" L x 3.82" W x 1.02" H (159.7mm x 97.0mm x 26.0mm).
In Stock: 4
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Open Frame |
| Number of Outputs | 3 |
| Voltage - Input | 85 ~ 265 VAC |
| Voltage - Output 1 | 5V |
| Voltage - Output 2 | 15V |
| Voltage - Output 3 | -15V |
| Voltage - Output 4 | - |
| Voltage - Output 5 | - |
| Voltage - Output 6 | - |
| Current - Output 1 | 8 A |
| Current - Output 2 | 1.5 A |
| Current - Output 3 | 1 A |
| Current - Output 4 | - |
| Current - Output 5 | - |
| Current - Output 6 | - |
| Power (Watts) | 50W |
| Applications | ITE (Commercial) |
| Voltage - Isolation | 3 kV |
| Efficiency | 72% |
| Operating Temperature | 0°C ~ 60°C (With Derating) |
| Features | Adjustable Output, DC Input Capable, Universal Input |
| Mounting Type | Chassis Mount |
| Size / Dimension | 6.29" L x 3.82" W x 1.02" H (159.7mm x 97.0mm x 26.0mm) |
| Approval Agency | CE |
| Standard Number | - |
Submit your RFQ for LWT50H-5FF and get a quote within 24 hours.
