Taiwan Semiconductor Corporation
IC REG LINEAR 9V 1A TO220
TS7809CZ C0G is a PMIC - Voltage Regulators - Linear manufactured by Taiwan Semiconductor Corporation. IC REG LINEAR 9V 1A TO220. Key specifications: mounting type Through Hole, operating temperature 0°C ~ 125°C (TJ), package / case TO-220-3, current - supply (max) 500 µA.
In Stock: 6,069
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Output Configuration | Positive |
| Output Type | Fixed |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 35V |
| Voltage - Output (Min/Fixed) | 9V |
| Voltage - Output (Max) | - |
| Voltage Dropout (Max) | 2V @ 1A (Typ) |
| Current - Output | 1A |
| Current - Quiescent (Iq) | 8 mA |
| Current - Supply (Max) | 500 µA |
| PSRR | 72dB (120Hz) |
| Control Features | Current Limit |
| Protection Features | Over Temperature |
| Operating Temperature | 0°C ~ 125°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 |
| Supplier Device Package | TO-220 |
TS7809CZ C0G is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| TS7808CZ C0G | Taiwan Semiconductor Corporation | IC REG LINEAR 8V 1A TO220 | 97% | View |
| TS7812CZ C0G | Taiwan Semiconductor Corporation | IC REG LINEAR 12V 1A TO220 | 92% | View |
| BA7809CP-E2 | Rohm Semiconductor | IC REG LINEAR 9V 1A TO220CP-3 | 85% | View |
| TS7805CZ C0G | Taiwan Semiconductor Corporation | IC REG LINEAR 5V 1A TO220 | 83% | View |
| BA7810CP-E2 | Rohm Semiconductor | IC REG LINEAR 10V 1A TO220CP-3 | 81% | View |
| BA7808CP-E2 | Rohm Semiconductor | IC REG LINEAR 8V 1A TO220CP-3 | 78% | View |
Submit your RFQ for TS7809CZ C0G and get a quote within 24 hours.
