Sumida America Components Inc.
FIXED IND 12UH 2.25A 54 MOHM SMD
CDRH104NP-120MC is a Fixed Inductors manufactured by Sumida America Components Inc.. FIXED IND 12UH 2.25A 54 MOHM SMD. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 100°C, package / case Nonstandard, current rating (amps) 2.25 A.
In Stock: 6,115
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | - |
| Material - Core | - |
| Inductance | 12 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 2.25 A |
| Current - Saturation (Isat) | - |
| Shielding | Shielded |
| DC Resistance (DCR) | 54mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 100°C |
| Inductance Frequency - Test | 1 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.386" L x 0.350" W (9.80mm x 8.90mm) |
| Height - Seated (Max) | 0.197" (5.00mm) |
Submit your RFQ for CDRH104NP-120MC and get a quote within 24 hours.
