CAP ALUM POLY 27UF 20% 63V T/H
63PZA27M8X12.5 is a Aluminum - Polymer Capacitors manufactured by Rubycon. CAP ALUM POLY 27UF 20% 63V T/H. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 63 V, package / case Radial, Can.
In Stock: 6,142
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Type | Polymer |
| Capacitance | 27 µF |
| Tolerance | ±20% |
| Voltage - Rated | 63 V |
| ESR (Equivalent Series Resistance) | 33mOhm |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Features | - |
| Ripple Current @ Low Frequency | 105 mA @ 120 Hz |
| Ripple Current @ High Frequency | 2.1 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.138" (3.50mm) |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.492" (12.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
63PZA27M8X12.5 is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| PLV1J270MDL1TD | Nichicon | CAP ALUM POLY 27UF 20% 63V T/H | 100% | View |
| A759EK276M1JAAE054 | KEMET | CAP ALUM POLY 27UF 20% 63V TH | 98% | View |
| PLX1H270MDL1 | Nichicon | CAP ALUM POLY 27UF 20% 50V T/H | 89% | View |
| 870135774002 | Würth Elektronik | CAP ALUM POLY 27UF 20% 50V T/H | 81% | View |
| 870056175004 | Würth Elektronik | CAP ALUM POLY 27UF 20% 80V T/H | 79% | View |
| 870135774001 | Würth Elektronik | CAP ALUM POLY 22UF 20% 50V T/H | 77% | View |
Submit your RFQ for 63PZA27M8X12.5 and get a quote within 24 hours.
