CAP ALUM 1000UF 20% 6.3V RADIAL
6.3WXA1000MEFC10X9 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 1000UF 20% 6.3V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 6.3 V, package / case Radial, Can.
In Stock: 3,407
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 1000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 6.3 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Ripple Current @ Low Frequency | 460 mA @ 120 Hz |
| Ripple Current @ High Frequency | 552 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.413" (10.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| ECA-1AHG102 | Panasonic Electronic Components | CAP ALUM 1000UF 20% 10V RADIAL | 85% | View |
| UPA0J102MPD1TA | Nichicon | CAP ALUM 1000UF 20% 6.3V RADIAL | 81% | View |
| URZ1C102MHD1TO | Nichicon | CAP ALUM 1000UF 20% 16V RADIAL | 74% | View |
| MAL214064102E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 1000UF 20% 10V RADIAL | 73% | View |
| MAL226055102E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 1000UF 20% 16V RADIAL | 65% | View |
| 860160275031 | Würth Elektronik | CAP ALUM 1000UF 20% 10V RADIAL | 60% | View |
Submit your RFQ for 6.3WXA1000MEFC10X9 and get a quote within 24 hours.
