CAP ALUM 6800UF 20% 50V SNAP
50VXG6800MEFC35X35 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 6800UF 20% 50V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 50 V, package / case Radial, Can - Snap-In.
In Stock: 1,907
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 6800 µF |
| Tolerance | ±20% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.91 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.3465 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 688LMB050M2ED | Cornell Dubilier / Illinois Capacitor | CAP ALUM 6800UF 20% 50V SNAP | 93% | View |
| 688LMB063M2DH | Cornell Dubilier / Illinois Capacitor | CAP ALUM 6800UF 20% 63V SNAP | 77% | View |
| ELXG800VND682MA50U | United Chemi-Con | CAP ALUM 6800UF 20% 80V SNAP | 70% | View |
| MAL216255682E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 6800UF 20% 16V SNAP | 69% | View |
| EEU-FC0J682L | Panasonic Electronic Components | CAP ALUM 6800UF 20% 6.3V RADIAL | 67% | View |
| MAL216256682E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 6800UF 20% 25V SNAP | 62% | View |
Submit your RFQ for 50VXG6800MEFC35X35 and get a quote within 24 hours.
