CAP ALUM POLY 33UF 20% 50V T/H
50PZA33M8X10 is a Aluminum - Polymer Capacitors manufactured by Rubycon. CAP ALUM POLY 33UF 20% 50V T/H. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 50 V, package / case Radial, Can.
In Stock: 5,796
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Type | Polymer |
| Capacitance | 33 µF |
| Tolerance | ±20% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | 32mOhm |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Features | - |
| Ripple Current @ Low Frequency | 95 mA @ 120 Hz |
| Ripple Current @ High Frequency | 1.9 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.138" (3.50mm) |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.394" (10.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
50PZA33M8X10 is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 336ULR020MEF | Cornell Dubilier / Illinois Capacitor | CAP ALUM POLY 33UF 20% 20V T/H | 76% | View |
| 870056175005 | Würth Elektronik | CAP ALUM POLY 33UF 20% 80V T/H | 67% | View |
| 50SEK33M | Panasonic Electronic Components | CAP ALUM POLY 33UF 20% 50V T/H | 61% | View |
| 25SEP33M | Panasonic Electronic Components | CAP ALUM POLY 33UF 20% 25V T/H | 57% | View |
| RNS1D330MDS1PX | Nichicon | CAP ALUM POLY 33UF 20% 20V T/H | 55% | View |
| RNS1D330MDS1 | Nichicon | CAP ALUM POLY 33UF 20% 20V T/H | 55% | View |
