CAP ALUM POLY HYB 100UF 50V SMD
50PFV100M10X10.5 is a Aluminum - Polymer Capacitors manufactured by Rubycon. CAP ALUM POLY HYB 100UF 50V SMD. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 125°C, voltage - rated 50 V, package / case Radial, Can - SMD.
In Stock: 2,982
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Hybrid |
| Capacitance | 100 µF |
| Tolerance | ±20% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | 28mOhm |
| Lifetime @ Temp. | 4000 Hrs @ 125°C |
| Operating Temperature | -55°C ~ 125°C |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Features | - |
| Ripple Current @ Low Frequency | 80 mA @ 120 Hz |
| Ripple Current @ High Frequency | 1.6 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.413" (10.50mm) |
| Surface Mount Land Size | 0.406" L x 0.406" W (10.30mm x 10.30mm) |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EHBSA035M1010810T | Eaton - Electronics Division | CAP ALUM HYBRID 0810 35V 100UF | 81% | View |
| A780KS107M1HLAV031 | KEMET | 100.UF 50.0V | 74% | View |
| HHXC350GRA101MHA0G | Chemi-Con | CAP ALUMHYB 100UF 20% 35V SMD | 73% | View |
| HHXC250ARA101MF80G | United Chemi-Con | CAP ALUM POLY 100UF 20% 25V SMD | 67% | View |
| GYC1H101MCW1GS | Nichicon | CAP ALUM POL HY 100UF 20% 50V SM | 62% | View |
| EEH-ZT1H101V | Panasonic Electronic Components | CAP ALUM POLY HYB 100UF 50V SMD | 59% | View |
