CAP ALUM 3300UF 20% 50V SNAP
50MXG3300MEFCSN22X30 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 3300UF 20% 50V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 50 V, package / case Radial, Can - Snap-In.
In Stock: 6,423
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 3300 µF |
| Tolerance | ±20% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.97 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.2655 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.866" Dia (22.00mm) |
| Height - Seated (Max) | 1.260" (32.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| B41252A6338M000 | EPCOS - TDK Electronics | CAP ALUM 3300UF 20% 50V SNAP | 96% | View |
| PF1H332MNN1832 | Chinsan (Elite) | ALUMINUM ELECTROLYTIC CAPACITORS | 85% | View |
| B41505F7338M7 | EPCOS - TDK Electronics | CAP ALUM 3300UF 20% 35V SNAP | 76% | View |
| MAL215838332E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 3300UF 20% 63V SNAP | 74% | View |
| EKMH800VNN332MA30U | United Chemi-Con | CAP ALUM 3300UF 20% 80V SNAP | 74% | View |
| EKMH800VNN332MQ50U | United Chemi-Con | CAP ALUM 3300UF 20% 80V SNAP | 70% | View |
