CAP ALUM 180UF 20% 450V SNAP
450VXR180MEFCSN35X35 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 180UF 20% 450V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 450 V, package / case Radial, Can - Snap-In.
In Stock: 6,363
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 180 µF |
| Tolerance | ±20% |
| Voltage - Rated | 450 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 7000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 870 mA @ 120 Hz |
| Ripple Current @ High Frequency | 1.218 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| B43252B5187M | EPCOS - TDK Electronics | CAP ALUM 180UF 20% 450V SNAP | 93% | View |
| 400HXG180MEFC25X25 | Rubycon | CAP ALUM 180UF 20% 400V SNAP | 92% | View |
| 400MXC180MEFC25X35 | Rubycon | CAP ALUM 180UF 20% 400V SNAP | 91% | View |
| 450MXG180MEFCSN22X40 | Rubycon | CAP ALUM 180UF 20% 450V SNAP | 82% | View |
| 420VXG180MEFCSN22X45 | Rubycon | CAP ALUM 180UF 20% 420V SNAP | 79% | View |
| MAL225969181E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 180UF 20% 500V SNAP | 71% | View |
Submit your RFQ for 450VXR180MEFCSN35X35 and get a quote within 24 hours.
