CAP ALUM 56UF 20% 450V RADIAL
450BXW56MEFR12.5X40 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 56UF 20% 450V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 450 V, package / case Radial, Can.
In Stock: 8,121
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 56 µF |
| Tolerance | ±20% |
| Voltage - Rated | 450 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 12000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 540 mA @ 120 Hz |
| Ripple Current @ High Frequency | 1.35 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.492" Dia (12.50mm) |
| Height - Seated (Max) | 1.654" (42.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EKXN401ELL560MJ45S | Chemi-Con | CAP ALUM 400V POLAR | 96% | View |
| 450LXW56MEFR14.5X25 | Rubycon | CAP ALUM 56UF 20% 450V RADIAL | 93% | View |
| 500HXW56MEFR14.5X35 | Rubycon | CAP ALUM 56UF 20% 500V RADIAL | 93% | View |
| 80ZLJ56MTA8X16 | Rubycon | CAP ALUM 56UF 20% 80V RADIAL | 61% | View |
| UAS2G560MHD61TN | Nichicon | CAP ALUM 56UF 20% 400V RADIAL | 61% | View |
| EKZN101ELL560MJC5S | United Chemi-Con | CAP ALUM 56UF 20% 100V RADIAL | 53% | View |
Submit your RFQ for 450BXW56MEFR12.5X40 and get a quote within 24 hours.
