CAP ALUM 120UF 20% 400V SNAP
400VXR120MEFCSN25X30 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 120UF 20% 400V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 400 V, package / case Radial, Can - Snap-In.
In Stock: 3,183
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 120 µF |
| Tolerance | ±20% |
| Voltage - Rated | 400 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 7000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 750 mA @ 120 Hz |
| Ripple Current @ High Frequency | 1.05 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.984" Dia (25.00mm) |
| Height - Seated (Max) | 1.260" (32.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EKMR401VSN121MP25S | United Chemi-Con | CAP ALUM 120UF 20% 400V SNAP | 99% | View |
| EKMM451VSN121MQ30U | United Chemi-Con | CAP ALUM 120UF 20% 450V SNAP | 93% | View |
| 861021483007 | Würth Elektronik | CAP ALUM 120UF 20% 450V SNAP | 92% | View |
| 420HXW120MEFR14.5X40 | Rubycon | CAP ALUM 120UF 20% 420V RADIAL | 90% | View |
| PV2W121MRT1845R | Chinsan (Elite) | ALUMINUM ELECTROLYTIC CAPACITORS | 83% | View |
| EKXJ421ELL121MM40S | United Chemi-Con | CAP ALUM 120UF 20% 420V RADIAL | 77% | View |
Submit your RFQ for 400VXR120MEFCSN25X30 and get a quote within 24 hours.
