CAP ALUM 100UF 20% 400V SNAP
400SXG100MEFCSN25X25 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 100UF 20% 400V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 400 V, package / case Radial, Can - Snap-In.
In Stock: 8,585
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 100 µF |
| Tolerance | ±20% |
| Voltage - Rated | 400 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 700 mA @ 120 Hz |
| Ripple Current @ High Frequency | 980 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.984" Dia (25.00mm) |
| Height - Seated (Max) | 1.063" (27.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EKWB401ELL101ML25S | Chemi-Con | CAP ALUM 100UF 20% 400V TH | 98% | View |
| EKHS451VSN101MP25S | Chemi-Con | CAP ALUM 100UF 20% 450V SNAP TH | 95% | View |
| EKWB421ELL101MK45S | Chemi-Con | CAP ALUM 100UF 20% 420V TH | 95% | View |
| REA1650101M450B | KYOCERA AVX | CAP ALUM 100UF 20% 450V RADIAL | 92% | View |
| EKXJ401ELL101MLP1S | United Chemi-Con | CAP ALUM 100UF 20% 400V RADIAL | 72% | View |
| RXW101M1VBK-0811S | SURGE | CAP ALUM 100UF 20% 35V RADIAL | 53% | View |
