CAP ALUM 120UF 20% 400V RADIAL
400BXW120MEFR16X40 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 120UF 20% 400V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 400 V, package / case Radial, Can.
In Stock: 5,309
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 120 µF |
| Tolerance | ±20% |
| Voltage - Rated | 400 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 12000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 860 mA @ 120 Hz |
| Ripple Current @ High Frequency | 1.935 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.295" (7.50mm) |
| Size / Dimension | 0.630" Dia (16.00mm) |
| Height - Seated (Max) | 1.654" (42.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EKXN451ELL121MM30S | Chemi-Con | CAP ALUM 120UF 20% 450V RADIAL | 95% | View |
| 420CXW120MEFR18X31.5 | Rubycon | CAP ALUM 120UF 20% 420V RADIAL | 85% | View |
| 100ZLJ120M10X25 | Rubycon | CAP ALUM 120UF 20% 100V RADIAL | 73% | View |
| UAS2G121MHD | Nichicon | CAP ALUM 120UF 20% 400V RADIAL | 70% | View |
| EKXJ221ELL121MJ50S | United Chemi-Con | CAP ALUM 120UF 20% 220V RADIAL | 68% | View |
| 600D127G060DL4 | Vishay Sprague | CAP ALUM 120UF 60V AXIAL | 56% | View |
Submit your RFQ for 400BXW120MEFR16X40 and get a quote within 24 hours.
