CAP ALUM 2700UF 20% 35V RADIAL
35YXH2700MEFCGC18X31.5 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 2700UF 20% 35V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 35 V, package / case Radial, Can.
In Stock: 9,364
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 2700 µF |
| Tolerance | ±20% |
| Voltage - Rated | 35 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 10000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.919 A @ 120 Hz |
| Ripple Current @ High Frequency | 4.17 A @ 100 kHz |
| Impedance | 15 mOhms |
| Lead Spacing | 0.295" (7.50mm) |
| Size / Dimension | 0.709" Dia (18.00mm) |
| Height - Seated (Max) | 1.319" (33.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UPJ1V272MHD | Nichicon | CAP ALUM 2700UF 20% 35V RADIAL | 85% | View |
| 381LQ272M160K052 | Cornell Dubilier Electronics (CDE) | CAP ALUM 2700UF 20% 160V SNAP | 77% | View |
| 100MXC2700MEFC25X50 | Rubycon | CAP ALUM 2700UF 20% 100V SNAP | 73% | View |
| EKYB250ELL272ML20S | United Chemi-Con | CAP ALUM 2700UF 20% 25V RADIAL | 67% | View |
| MAL225621272E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 2700UF 20% 50V SNAP | 59% | View |
| B41605E8278M9 | EPCOS - TDK Electronics | CAP ALUM 2700UF 20% 63V RADIAL | 59% | View |
