CAP ALUM 15000UF 20% 35V SNAP
35MXG15000MEFCSN25X50 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 15000UF 20% 35V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 35 V, package / case Radial, Can - Snap-In.
In Stock: 6,055
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 15000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 35 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 3.72 A @ 120 Hz |
| Ripple Current @ High Frequency | 4.278 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.984" Dia (25.00mm) |
| Height - Seated (Max) | 2.047" (52.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| LP153M035H9P3 | Cornell Dubilier Electronics (CDE) | CAP ALUM 15000UF 20% 35V SNAP | 98% | View |
| LGU1E153MELA | Nichicon | CAP ALUM 15000UF 20% 25V SNAP | 84% | View |
| LGU1E153MELC | Nichicon | CAP ALUM 15000UF 20% 25V SNAP | 83% | View |
| VHT15000M25 | NTE Electronics, Inc | CAP ALUM 15000UF 20% 25V RADIAL | 78% | View |
| ELXZ6R3ELL153MM35S | United Chemi-Con | CAP ALUM 15000UF 20% 6.3V RADIAL | 71% | View |
| LGU1C153MELZ | Nichicon | CAP ALUM 15000UF 20% 16V SNAP | 63% | View |
Submit your RFQ for 35MXG15000MEFCSN25X50 and get a quote within 24 hours.
