CAP ALUM 5600UF 20% 35V SNAP
35MXC5600MEFCSN25X25 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 5600UF 20% 35V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 35 V, package / case Radial, Can - Snap-In.
In Stock: 7,019
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 5600 µF |
| Tolerance | ±20% |
| Voltage - Rated | 35 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.13 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.4495 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.984" Dia (25.00mm) |
| Height - Seated (Max) | 1.063" (27.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EGPD250ELL562ML30H | United Chemi-Con | CAP ALUM 5600UF 20% 25V RADIAL | 75% | View |
| EKYB100ELL562MK35S | United Chemi-Con | CAP ALUM 5600UF 20% 10V RADIAL | 68% | View |
| 6.3ZLJ5600M12.5X30 | Rubycon | CAP ALUM 5600UF 20% 6.3V RADIAL | 67% | View |
| EEU-FM0J562SB | Panasonic Electronic Components | CAP ALUM 5600UF 20% 6.3V RADIAL | 67% | View |
| B41252A8568M000 | EPCOS - TDK Electronics | CAP ALUM 5600UF 20% 63V SNAP | 60% | View |
| MAL212515562E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 5600UF 20% 16V AXIAL | 57% | View |
Submit your RFQ for 35MXC5600MEFCSN25X25 and get a quote within 24 hours.
