CAP ALUM 120UF 20% 350V SNAP
350MXC120MEFCSN25X25 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 120UF 20% 350V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 350 V, package / case Radial, Can - Snap-In.
In Stock: 6,317
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 120 µF |
| Tolerance | ±20% |
| Voltage - Rated | 350 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 750 mA @ 120 Hz |
| Ripple Current @ High Frequency | 1.05 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.984" Dia (25.00mm) |
| Height - Seated (Max) | 1.063" (27.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| LDQ2G121MERZGA | Nichicon | CAP ALUM 120UF 20% 400V RADIAL | 95% | View |
| UPT2G121MHD | Nichicon | CAP ALUM 120UF 20% 400V RADIAL | 93% | View |
| 381LR121M400H022 | Cornell Dubilier Electronics (CDE) | CAP ALUM 120UF 20% 400V SNAP | 92% | View |
| EKWA421ELL121ML35S | United Chemi-Con | RADIAL ALUMINUM ELECTROLYTIC CAP | 90% | View |
| 400SXC120MEFCSN30X25 | Rubycon | CAP ALUM 120UF 20% 400V SNAP | 90% | View |
| 450CXW120MEFR18X31.5 | Rubycon | CAP ALUM 120UF 20% 450V RADIAL | 88% | View |
