CAP ALUM 33UF 20% 350V RADIAL
350BXC33MEFCGC16X20 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 33UF 20% 350V RADIAL. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 350 V, package / case Radial, Can.
In Stock: 9,577
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 33 µF |
| Tolerance | ±20% |
| Voltage - Rated | 350 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 12000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 360 mA @ 120 Hz |
| Ripple Current @ High Frequency | 900 mA @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.295" (7.50mm) |
| Size / Dimension | 0.630" Dia (16.00mm) |
| Height - Seated (Max) | 0.866" (22.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 350BXC33MEFC16X20 | Rubycon | CAP ALUM 33UF 20% 350V RADIAL | 100% | View |
| 400WXA33MEFCGC18X20 | Rubycon | CAP ALUM 33UF 20% 400V RADIAL | 91% | View |
| 860021378014 | Würth Elektronik | CAP ALUM 33UF 20% 400V RADIAL | 64% | View |
| EKMG351ELL330ML25S | United Chemi-Con | CAP ALUM 33UF 20% 350V RADIAL | 63% | View |
| UBX2A330MPL | Nichicon | CAP ALUM 33UF 20% 100V RADIAL | 57% | View |
| EKMQ351ELL330MK25S | United Chemi-Con | CAP ALUM 33UF 20% 350V RADIAL | 56% | View |
Submit your RFQ for 350BXC33MEFCGC16X20 and get a quote within 24 hours.
