CAP ALUM 330UF 20% 315V SNAP
315VXR330MEFCSN35X30 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 330UF 20% 315V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 315 V, package / case Radial, Can - Snap-In.
In Stock: 6,051
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 330 µF |
| Tolerance | ±20% |
| Voltage - Rated | 315 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 7000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.2 A @ 120 Hz |
| Ripple Current @ High Frequency | 1.68 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.260" (32.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 400VXR330MEFCSN35X40 | Rubycon | CAP ALUM 330UF 20% 400V SNAP | 93% | View |
| B43545B9337M000 | EPCOS - TDK Electronics | CAP ALUM 330UF 20% 400V SNAP | 76% | View |
| 63ZLJ330M10X25 | Rubycon | CAP ALUM 330UF 20% 63V RADIAL | 68% | View |
| UBT1K331MHD | Nichicon | CAP ALUM 330UF 20% 80V RADIAL | 61% | View |
| UBW1H331MHD | Nichicon | CAP ALUM 330UF 20% 50V RADIAL | 59% | View |
| 16YXG330MEFCTA8X9 | Rubycon | CAP ALUM 330UF 20% 16V RADIAL | 56% | View |
Submit your RFQ for 315VXR330MEFCSN35X30 and get a quote within 24 hours.
