CAP ALUM 330UF 20% 25V RADIAL
25RX30330M10X12.5 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 330UF 20% 25V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 130°C, voltage - rated 25 V, package / case Radial, Can.
In Stock: 4,746
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 330 µF |
| Tolerance | ±20% |
| Voltage - Rated | 25 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 130°C |
| Operating Temperature | -40°C ~ 130°C |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Ripple Current @ Low Frequency | 434 mA @ 120 Hz |
| Ripple Current @ High Frequency | - |
| Impedance | 150 mOhms |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.551" (14.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UBX1E331MHL1TO | Nichicon | CAP ALUM 330UF 20% 25V RADIAL | 88% | View |
| 35RX30330M10X16 | Rubycon | CAP ALUM 330UF 20% 35V RADIAL | 75% | View |
| UBW1V331MPD | Nichicon | CAP ALUM 330UF 20% 35V RADIAL | 75% | View |
| UBW1C331MPD1TD | Nichicon | CAP ALUM 330UF 20% 16V RADIAL | 72% | View |
| MAL216050331E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 330UF 20% 35V RADIAL | 70% | View |
| 16RX30330MTA8X11.5 | Rubycon | CAP ALUM 330UF 20% 16V RADIAL | 64% | View |
Submit your RFQ for 25RX30330M10X12.5 and get a quote within 24 hours.
