CAP ALUM 10UF 20% 200V RADIAL
200WXA10MEFCT810X9 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 10UF 20% 200V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 200 V, package / case Radial, Can.
In Stock: 7,497
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 10 µF |
| Tolerance | ±20% |
| Voltage - Rated | 200 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Ripple Current @ Low Frequency | 85 mA @ 120 Hz |
| Ripple Current @ High Frequency | 127.5 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.413" (10.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UPS2D100MPD1TD | Nichicon | CAP ALUM 10UF 20% 200V RADIAL | 98% | View |
| UPW2D100MPH | Nichicon | CAP ALUM 10UF 20% 200V RADIAL | 98% | View |
| UPM2D100MPD1TD | Nichicon | CAP ALUM 10UF 20% 200V RADIAL | 93% | View |
| MAL215267109E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 10UF 20% 450V RADIAL | 70% | View |
| 100PX10MEFC5X11 | Rubycon | CAP ALUM 10UF 20% 100V RADIAL | 62% | View |
| ED1H100MP20511ERU | Chinsan (Elite) | ALUMINUM ELECTROLYTIC CAPACITORS | 60% | View |
Submit your RFQ for 200WXA10MEFCT810X9 and get a quote within 24 hours.
