CAP ALUM 120UF 20% 160V RAD TH
160TXW120MEFC8X50 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 120UF 20% 160V RAD TH. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 160 V, package / case Radial, Can.
In Stock: 7,330
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 120 µF |
| Tolerance | ±20% |
| Voltage - Rated | 160 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 12000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 540 mA @ 120 Hz |
| Ripple Current @ High Frequency | 756 mA @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.138" (3.50mm) |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 2.067" (52.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
160TXW120MEFC8X50 is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 860040878006 | Würth Elektronik | CAP ALUM 120UF 20% 100V RADIAL | 76% | View |
| UCY2C121MHD | Nichicon | CAP ALUM 120UF 20% 160V RADIAL | 75% | View |
| B43508A9127M | EPCOS - TDK Electronics | CAP ALUM 120UF 20% 400V SNAP | 63% | View |
| B43504A9127M007 | EPCOS - TDK Electronics | CAP ALUM 120UF 20% 400V SNAP | 63% | View |
| EKMZ451VSN121MP25S | United Chemi-Con | CAP ALUM 120UF 20% 450V SNAP | 61% | View |
| ELXZ630ELL121MJ16S | United Chemi-Con | CAP ALUM 120UF 20% 63V RADIAL | 54% | View |
Submit your RFQ for 160TXW120MEFC8X50 and get a quote within 24 hours.
