CAP ALUM 220UF 20% 100V RADIAL
100PX220MEFCG412.5X20 is a Aluminum Electrolytic Capacitors manufactured by Rubycon. CAP ALUM 220UF 20% 100V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 100 V, package / case Radial, Can.
In Stock: 9,993
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 220 µF |
| Tolerance | ±20% |
| Voltage - Rated | 100 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 560 mA @ 120 Hz |
| Ripple Current @ High Frequency | 672 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.492" Dia (12.50mm) |
| Height - Seated (Max) | 0.846" (21.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MAL211928221E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 220UF 63V AXIAL | 77% | View |
| UBX1K221MHL1TN | Nichicon | CAP ALUM 220UF 20% 80V RADIAL | 76% | View |
| ELXV101ELL221ML25S | United Chemi-Con | CAP ALUM 220UF 20% 100V RADIAL | 76% | View |
| UBW1J221MHD1TO | Nichicon | CAP ALUM 220UF 20% 63V RADIAL | 74% | View |
| EEU-FC1V221 | Panasonic Electronic Components | CAP ALUM 220UF 20% 35V RADIAL | 73% | View |
| 678D227M063EK4DE3 | Vishay Sprague | CAP ALUM 220UF 20% 63V RADIAL | 67% | View |
Submit your RFQ for 100PX220MEFCG412.5X20 and get a quote within 24 hours.
